XCMG RP403 Asphalt Paver
Machine weight :12000kg
Theoretical Productivity:300t/h
Basic paving width:2.5m
Max. paving width:4.2m
Max. paving thickness:200mm
Paving speed:0~11m/min
Travel speed:0~3.6km/h
Engine model:BF4M2012C
Rated Power:75KW/2200rpm
Dimension:6400X2580X3830mm
Availability: | |
---|---|
Quantity: | |
RP403
SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.
We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.
XCMGR RP403L ASPHALT PAVER | ||
Basic paving width | 2.5m | |
Max. paving width | 4.2m | |
Max. paving thickness | 200mm | |
Paving speed | 0~3.6m/min | |
Travel speed | 0~11km/h | |
Theoretical Productivity | 300t/h | |
Hopper Capacity | 13t | |
Gradeability | 20% | |
Pavement evenness | 3mm/3m | |
Transverse levelling accuracy | ±0.03% | |
Centre crown ratio | 0~+3% | |
Engine model | BF4M2012C | |
Engine power | 75kW | |
Engine speed | 2200r/min | |
Machine weight | 12t | |
Dimension | 6400X2580X3830mm | |
Vibrator speed | 0~1470r/min | |
Screed heating | Gas heating | |
Auger and conveyor control | Automatic Control by Ultrasonic Sensors | |
Automatic levelling control | Simulation control of electronic automatic leveler | |
Packing | Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity. | |
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice |
The RP403 paver is the first full-hydraulic small crawler asphalt paver in China. The whole machine adopts full hydraulic drive and electro-hydraulic automatic control, advanced technology and reliable performance.
The minimum width of the whole machine is only 1.8 meter, which is the smallest among domestic products. Due to its compact shape, it is widely used in large scale paving, including sidewalks, bike lanes, farm roads and small roads.
The paving width can be stepless adjusted from 0.8 meters (if installed with width limit device) to 4.5 meters, and is especially suitable for the maintenance of roads.
Performance Characteristics:
* The device is equipped with a water-cooled turbocharged diesel engine (75kW/2000rpm), a powerful three-phase alternator with
generator management system, and the generator adopts independent drive technology.
* The hydraulic system adopts load-sensitive control technology on both sides.
* The hoppers can be individually folded and oscillating follow-up inference.
* The electronic control system design is a CAN bus technology platform, a network control system of the CPU control technology, and an automatic leveling device.
