SINOTRUK HOWO 4X2 Van Truck(7 T)
Model: ZZ5047XXYD3415C145
Chassis Model:ZZ1047D3415C145
Cab:2080 single cab,with A/C
Engine:YUNNEI brand,YN4102QBZL, 116hp
Transmission: WLY6T46,6F&1R
Steering: Left hand driving
Axles: 2.7T/7.2T
Tire: 8.25R16 Radial tire 6 pieces with 1 Spare tire.
Carriage Internal Dimension:4200x2150x2150 mm
Steel thickness of Carriage：Floor:3mm/Side:1.5mm
| Quantity: | |
|---|---|
ZZ5047XXYD3415C145
SINOTRUK HOWO
1.Performance: Strong engine power, large torque, high power transmission efficiency, good fuel economy, suitable for all walks of life.
2.Structure: high strength material, lightweight chassis and box design, less spring, strong bearing capacity.
3.Cities, suburbs, mining areas and rural areas;
4.short distance transportation generally within 200 kilometers;
5.the main transport sand, construction slag, building materials, waste transportation;
Low requirements for speed and price sensitivity.
SINOTRUK HOWO 4X2 LIGHT CARGO TRUCK SPECIFICATION | ||
Truck Model | ZZ1047D3415C145(Left Hand Drive ) | |
Truck Brand | SINOTRUK-HOWO | |
Dimension (LxWxH) (unloaded)mm | 5995×2240×3350 | |
Cargo body | 4200 x2150x2150 mm | |
Cargo body thickness (mm) | Bottom:3 mm, side:1.5 mm | |
Approaching angle/ Departure angel (°) | 20/18 | |
Overhang (front/rear) (mm) | 1160/1475 | |
Wheel base (mm) | 3360 | |
Max. Driving speed (km/h) | 95 | |
Front axle loading capacity (kg) | 2700 | |
Rear axle loading capacity(kg) | 7200 | |
Curb weight (kg) | 2430 | |
Gross vehicle weight | 7000 | |
Cab | 2080 single cab,with A/C | |
Engine Model | Model | YUNNEI brand,YN4102QBZL, 116hp |
Rated Power(kw/rpm) | 85/3000 | |
Clutch | Diaphragm spring clutch,single plate | |
Transmission | Model | WLY6T46,6F&1R |
Brake system
| Service brake | Dual circuit air brake |
Parking Brake | Spring energy, compressed air operating on rear wheels | |
Steering system | Model | Power steering,Adjustable steering wheel. (left hand driving) |
Front axle | (2.7T)Forging I-beam,Drum brake. | |
Rear axle | (7.2T) Pressed welding axle housing drum brake. | |
Tire | 8.25R16 Radial tire 6 pieces with 1 Spare tire. | |
Electrical system
| Type | SINOTRUK CAN bus system with VCO instrument |
Voltage | 12V, | |
Batteries | 2*12V, 120 Ah | |
Alternator | 28V/35A | |
Starter | 4.5Kw | |
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light. | ||
Oil Tank | 120L fuel tank | |
Packing | Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity. | |
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice | ||
We are the agency for SINOTRUK wholesale truck series, we can supply HOWO tractor trucks, HOWO dump trucks, trailer truck, truck parts, agricultural machinery, Construction machinery and parts,HOWO concrete mixer trucks, special trucks and so on.we can supply trucks for our clients with good quality and competitive price, because we get directly support from the CNHTC factory.
Main products
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
