SINOTRUK HOWO 4X2 Stake Cargo Truck(12 T)
Model: ZZ5107CCYG4215C1
Chassis Model: ZZ1107G4215C1
Cab:2080 extended cab,with A/C
Engine:YUCHAI brand,YC4E160-33, 160hp
Transmission: DC6J65TC,6F&1R
Steering: Left hand driving
Axles: 3.2T/8.0T
Tire: 8.25R20 Radial tire 6 pieces with 1 Spare tire.
Carriage Internal Dimension:5200x2300x550+1750 mm
Steel thickness of Carriage：Floor:3mm/Side:1.5mm
| Quantity: | |
|---|---|
ZZ5107CCYG4215C1
SINOTRUK HOWO
1.Performance: Strong engine power, large torque, high power transmission efficiency, good fuel economy, suitable for all walks of life.
2.Structure: high strength material, lightweight chassis and box design, less spring, strong bearing capacity.
3.Cities, suburbs, mining areas and rural areas;
4.short distance transportation generally within 200 kilometers;
5.the main transport sand, construction slag, building materials, waste transportation;
Low requirements for speed and price sensitivity.
SINOTRUK HOWO 4X2 LIGHT STAKE CARGO TRUCK SPECIFICATION | ||
Truck Model | ZZ1107G4215C1(Left Hand Drive ) | |
Truck Brand | SINOTRUK-HOWO | |
Dimension (LxWxH) (unloaded)mm | 7445×2500×3750 | |
Cargo body | 5200x2300x550+(1750 Stake) mm | |
Cargo body thickness (mm) | Bottom:3 mm, side:1.5 mm | |
Approaching angle/ Departure angel (°) | 27/20 | |
Overhang (front/rear) (mm) | 1240/2005 | |
Wheel base (mm) | 4200 | |
Max. Driving speed (km/h) | 95 | |
Front axle loading capacity (kg) | 3200 | |
Rear axle loading capacity(kg) | 8000 | |
Curb weight (kg) | 4735 | |
Gross vehicle weight(kg) | 12000 | |
Cab | 2080 Extended cab,with A/C | |
Engine Model | Model | YUCHAI brand,YC4E160-33, 160hp |
Rated Power(kw/rpm) | 118/2600 | |
Clutch | Diaphragm spring clutch,single plate | |
Transmission | Model | DC6J65TC,6F&1R |
Brake system
| Service brake | Dual circuit air brake |
Parking Brake | Spring energy, compressed air operating on rear wheels | |
Steering system | Model | Power steering,Adjustable steering wheel. (left hand driving) |
Front axle | (3.2T)Forging I-beam,Drum brake. | |
Rear axle | (8.0T) Pressed welding axle housing drum brake. | |
Tire | 8.25R20 Radial tire 6 pieces with 1 Spare tire. | |
Electrical system
| Type | SINOTRUK CAN bus system with VCO instrument |
Voltage | 12V, | |
Batteries | 2*12V, 120 Ah | |
Alternator | 28V/35A | |
Starter | 4.5Kw | |
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light. | ||
Oil Tank | 120L fuel tank | |
Packing | Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity. | |
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice | ||
