Telehandler Hydraulic Wheel loader With Backhoe

SAM388 Backhoe Loader

Loading bucket capacity: 1m³

Overall working weight 8400kg

Digging bucket capacity0.3m³

Rated load8200kg

Engine Model: YC4A105Z-T20 or cummins

Gross Power:75/2400 kW / rpm

Availability:
Quantity:
  • SAM388

  • SAM

Product Description

企业横幅 6-2

SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.



We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.

新组合 1

The Main Performance Parameter of Backhoe Loader SAM388

Overall Operating Weight

8200KG

Final Reducer

Single Stage Final Reducer

Transport Dimension

Rated Loader of Axle

4/18.5t

L*W*H

6150×2250×3763mm

Transmission System

Wheel base

2200mm

Torque Converter

Min. Ground Clearance

300mm

Model

YJ280

Bucket Capacity

1.0m3

Type

Single-stage Three Elements

Breakout Force

38KN

Max. Efficiency

84.4%

Loading Lifting Capacity

2500KG

Inlet Pressure

0.4Mpa—0.55 Mpa

Bucket Dumping Height

2742mm

Outlet Pressure

1.2Mpa—1.5 Mpa

Bucket Dumping Distance

1062mm

Cooling Method

Oil-cooling Pressure Circulation

Digging Depth

52mm

Gearbox

Backhoe Capacity

0.3 m3

Type

Fixed Shaft Power Transmission

Max. Digging Depth

4082mm

Oil Pressure of Clutch

1373Kpa—1569 Kpa

Swing Angle of Excavator Grab

190o

Gears

Two Gears Ahead, Two Gears Astern

Max. Pulling Force

39KN

Max.Speed

22Km/h

Engine

Tyre

Mode

YC4A105Z-T20

or cummins

Model

14-17.5/19.5L-24

Type

 turbocharging four-stroke

Pressure of Front wheel

0.22 Mpa

Cylinder-Inside Diameter*Stroke

4—105

Pressure of Back Wheel

0.22 Mpa

Rated Power

75KW/100HP

Brake System

Rated Speed

2400r/min

Service Brake

Air Over Oil Caliper Brake

Min. Fuel Consumption

235g/kw.h

External Type

Max.Torque

310NM

Self-regulation

Displacement

4.3L

Self-balance

Steering System

Emergency Brake

Operation Power Implementing brake

Model of Steering Device

BZZ5-250

Manual Operation Power Terminating Brake

Steering Angle

±36 o

Hydraulic System

Min. turning radius

6581mm

Digging Power of Excavator Grab

46.5KN

Pressure of the system

12Mpa

Digging Power of Dipper

31KN

Axle

Bucket Lifting Time

5.4S

Manufacturer

Feicheng Axle Factory

Bucket Lowering Time

3.1S

Main Transmission Type

Double Reduction

Bucket Discharge Time

2.0S

The parameters are subject to change without notice

新组合 2

Focusing on customer value and emphasizing customer experiences, our loader is the first-choice equipment for the production organization in the fields of ports, mines, engineering constructions, and logistics.



1. Our exclusive high torque and high efficiency drive chain features reasonable matching.

2. Our characteristic super-heavy-load structure parts are free of redundant weight.

3. With extended wheelbase, the working capacity and stability are leading the industry.

4. The centering design of main hinge joints reduces the turning radius and lowers the tire wear and energy consumption.

5. The ergonomically design cab adopts integral skeleton structure, delicate interior trim parts, and sound insulation and noise reduction measure, featuring broad visual field, super-large space, and high operation comfort.

6. The diversified configurations and complete attachments comprehensively adapt to the construction needs in different regions and under different working conditions.
