HOWO Truck-Mounted Synchronous Asphalt Chip Sealers

ZZ1257N4641W(6x4)

HOWO Truck-Mounted Synchronous Asphalt Chip Sealers

Cab:HW76,with one sleep,with A/C

Engine:WD615.69; 336hp; Euro II

Transmission: HW19710 ,10 forward and 2 reverse

Steering: ZF8118Left hand driving

Axles: Front:9000kg &  Rear:2*16000kg

Tire: 12.00R20 radial tire,with 1 Spare tire.

Working speed:1.2~6.5km/h

Asphalt tank rated capacity:7000L

Chip storehouse capacity:10m³

Spray width:≤3.8m

Availability:
Quantity:
  • ZZ1257N4641W

  • SINOTRUK HOWO

Product Description

新重汽 32

Our company aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.

新重汽 36

SINOTRUK HOWO 6x4 Truck-Mounted Synchronous Asphalt Chip Sealers

SPECIFICATIONS

Model

LMT5250TFC

Chassis

ZZ1257N4641W

Type

Cab-over-Engine 6×4 Rear driver

Engine model

WD615.69

Powerkw/r/min

247/2200

No. of the cab persons

3

Dimension (mm)

10450×2498×3430

Kurb weightkg

15075

Max. masskg

25000

Wheel basemm



Front wheel

2041

Rear wheel

1830/1830

Axes basemm

4600+1350

Before suspend mm

1500

Rear suspend mm

2445/2420

Max. truck speedkm/h

102

Fuel consumption per one hundred kilometerL

19

Working speedkm/h

1.2~6.5

Asphalt tank rated capacityL

7000

Chip storehouse capacitym3

10

Chip diametermm

5-25

Spray widthm

≤3.8

Spray valueL/m2

0.6~2.5

Asphalt working permit viscosityCst

≤300

Cleaning system Max. pneumaticMPa

0.6

Hydraulic system Max. pressMPa

20

Packing

Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.

The manufacturer reserves the right of technical alteration /change for better improvement without prior notice

Chip Sealer can be used for paving underlying seal coat and surface seal coat, paving wearing course for new or old road surface, separately spraying asphalt and chippings. it can be used highway, bridge, also used country road.



Strong Point

★  The main parts import many oversea. Burner (Italy RIALLO), Asphalt pump (Belgium JOHSON), Hydraulic system (German REXROTH), Control system (German Siemens), Hydraulic motor (Italy SAI).

★  All operations can be performed by one operator in Cab, through it the computer touch screen.

★It can spray various asphalt, hot asphalt, modify asphalt and emulsified asphalt

★Asphalt and Chippings application rate is controlled by computer, and is independent of the truck speed.

★An intelligent linkage between asphalt and chippings spreading systems.

★Advanced heating and circulating system, to ensure the asphalt pipelines and nozzles  “not to be blocked”   and “not need to be washed by diesel oil” (“to be washed by high pressure air”)

★Uniquely combined aggregate bin have two parts, one is immovable(4m³) and the other is uplifted(8m³), Advantage: Solve the small of the hopper; conquer the uplifted higher barycenter. Disadvantage: The hopper poor connectivity.

★ Equipped with flexible hand spray system.

★  To realize fully three-overlapping asphalt spraying at two sides.

★Opening and closing of the doors of aggregate bin are controlled by pneumatic control valve. Every door of aggregate bin and nozzle can be controlled separately.

★  Spreading(spraying) width can be freely adjusted during working process.

★Equipped with Monitoring System, working specifications can be displayed on display screen at any time.
