HOWO Log Truck(6x6)

SINOTRUK HOWO Log Truck(6x6)

Model:ZZ4257S3557A

Cab:HW76,with one sleep,with A/C

Engine:WD615.47.; 371hp; Euro II

Transmission: HW19710,10 forward and 2 reverse.

Steering: ZF8118Left hand driving

Transfer case: 2000

Axles: Front:7000kg &  Rear: 2*16000kg

Tire:12.00R20 radial tyre,with 1 Spare tire

Fifth:90#(3.5 inch)  Oil Tank:400L

Drag bar size:8750*270*12mm

Log length 13000mm

Availability:
Quantity:
  • ZZ4257S3557A

  • SINOTRUK HOWO

Product Description

新重汽 32

Our company aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.

新重汽 34

SINOTRUK LOG SEMI TRAILER

Drag bar size

8750*270*12(mm)Log length 13000mm

U type log Bracket

2 sets(Inside width 2800mm,Column high 2000mm) Rear U type log Bracket

Front baffle

Front baffle high 1500mm,thickness 8mm

Axles

16T*/per*2 ,FUHUA Brand

Tir

12.00R20 radial tyre

Rim

8.5-20

Suspension

Single-point suspension

SINOTRUK HOWO 6x6 TRACTOR TRUCK

Truck Model

ZZ4257S3557A(Left Hand Drive )

Truck Brand

SINOTRUK-HOWO

Dimension (LxWxH) (unloaded)mm

10500×3550×3950

Approaching angle/ Departure angel (°)

32/74

Overhang (front/rear) (mm)

1578/700

Min Turning Radius(m)

9m

Wheel base (mm)

3500+1400

Max. Driving speed (km/h)

95

Front axle loading capacity (kg)

7000

Rear axle loading capacity(kg)

2*16000

Curb weight (kg)

15500

Traction weight (kg)

55000

Cab Model

SINOTRUK HW76 Lengthen cab,single bunk,all steel forward control, 55o hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds, laminate windscreen, with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, adjustable roof flap, with stereo radio/MP3, sun visor, and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt, air conditioner,Front protection grille.

Engine Model

Model

WD615.47(EURO II),371hp,6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection

Rated Power(kw/rpm)

273/2200

Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 71℃ opening begin, Rigid fan

Engine protection.

Clutch

SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance

Transmission

Model

SINOTRUK HW19710 transmission ,10 forward and 2 reverse

Brake system



Service brake

Dual circuit compressed air brake

Parking Brake

(emergency brake)

Spring energy, compressed

Steering system

Model

ZF8118 Steering Gear Box ,hydraulic steering with power assistance.

(Left hand driving)

Front axle

SINOTRUK STR steering drive Front Axle with drum brakes.

Transfer case

2000

Rear axle

SINOTRUK 2*16000kg Double Reduction Drive Axle, Pressed axle housing, central single reduction with planetary wheel reduction and with differential locks between wheels and axles,ratio:4.8;

strengthened design, loading capacity and reliability have been increased greatly.

Wheels &Tire

Rims:8.5-20 10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire.

Electrical system

Electrics Operating voltage

24V,negative grounded

Starter

24V,7.5 Kw

Alternator

3-phase,28V,1500 W

Batteries

2x12 V,165 Ah

horn,headlamps,fog lights,brake lights,indicators and reverse light

Oil Tank

400L fuel tank

Fifth

90#(3.5 inch)

Packing

Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.

The manufacturer reserves the right of technical alteration /change for better improvement without prior notice
