You are here: Home » Products » Truck » Other Vehicle » HOWO Truck-Mounted Intelligent Asphalt Distributors 13000L

HOWO Truck-Mounted Intelligent Asphalt Distributors 13000L

ZZ1257N4641W(6x4)

HOWO Truck-Mounted Intelligent Asphalt Distributors

Cab:HW76,with one sleep,with A/C

Engine:WD615.69; 336hp; Euro II

Transmission: HW19710 ,10 forward and 2 reverse

Steering: ZF8118Left hand driving

Axles: Front:9000kg &  Rear:2*16000kg

Tire: 12.00R20 radial tire,with 1 Spare tire.

Working Speed :2.510.5km/h

Max. Spraying Width:6m

Heat Conducting oil with in Rear Nozzle and

Spraying bar Bitumen tank, Bitumen Pump

Availability:
Quantity:
  • ZZ1257N4641W

  • SINOTRUK HOWO

Product Description

新重汽 32

Our company aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.

新重汽 36

SINOTRUK HOWO 6x4 Truck-Mounted Intelligent Asphalt Distributors SPECIFICATIONS

DimensionL/W/H

10500×2496×3400

Tank Capacity

13000Liters

Chassis Model

ZZ1257M4647W

Chassis Company

SINO TRUCK

Truck Type

Cabin over engine 6×4 Rear Driver

Tyre Specification

12.00R20

Approach/Departure Angle

15°/12°

 Engine Powerhp/r/min

247/2200

Fuel

Diesel

Engine Model

WD615.69 6Cylinders 4 Stroke

Truck Displacement Standard

EURO II

Passengers

2

Max. Truck Speedkm/h

90

Total Mass(kg)

25000

Kerb. Mass(kg)

6910

Working Speedkm/h

2.510.5

Bitumen DisplacementL/r

0.86

Max. Spraying Widthm

6

Spraying ValueL/m2

0.3-3

Max. Pressure of Hydraulic System (MPa)

20

Transfer oil

Heat Conducting oil with in Rear Nozzle and Spraying bar Bitumen tank, Bitumen Pump

Cleaning

High pressure air

Packing

Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.

The manufacturer reserves the right of technical alteration /change for better improvement without prior notice

*MAIN FEATURES

-circular section tank, manufactured with 4mm thick carbon steel

-100mm rock wool insulation to keep temperature

-1mm thick stainless steel

-manhole dia. 70mm

-heated by Italy Riello diesel automatic burner

-”U”shaped flame tubes inside the tank with external wind proof stack

-diesel oil fuel tank from Chassis

-safety devices for automatic burner shut down when pre-set temperature reached and when bitumen

lever lower than minimum required

-digital thermometer on control box and dial thermometer on thank, scale 0-300℃

-bitumen pump installed on the tank head,capacity 680liters/m,it can used to unloading, recirculation

in spray bar, spraying and transfer to other tank

-spraying value you can setting on the cabin computer, it’s a high precision. And the suggest truck

speed is 1500rpm-2000rpm

-spray bar width is 2.5 m, with foldable extensions for spraying up to 6m width. Heat conducting oil

circulation with this spray bar, it can quickly to heat the Bitumen temperature, when you forget

cleaning, you can heat it and the nozzle no block.

-adjustable spraying width by cabin computer, you control the nozzles open and close

-possibility of cleaning bitumen pump, pipes and spray bar normally only choice the air. Spraying very

stick bitumen by suction of diesel oil through built-in circuit from diesel tank and quick coupling with

flexible hoses for cleaning by air from truck circuit

-heating conducting oil automatic circulation in Bitumen pump, bitumen tank, bitumen sprayer, it can

heating bitumen quickly and keep the bitumen temperature

-control box to be installed in cab including:

      -main switch

      -PTO switch

      -Hydraulic oil Cooler fan switch

     -Bitumen spraying value

      -Bitumen Spraying width

      -Bitumen pump speed automatic

      -Speed digital display

      -pressure digital display

      -Bitumen Pump working position

      -nozzle workingsite display

-bitumen temperature and burner block light in tank head

-burner control box on the right of the tank

-control box in rear plate

       - nozzle switch

       -power switch

       -Bitumen pump switch

       -heat conducting oil switch

       -adjustable Bitumen pump speed

-hand spray lance, 3 nozzles with 5m long flexible hose

新沥青洒布车 1


企业横幅 6-7

We are the agency for SINOTRUK wholesale truck series, we can supply HOWO tractor trucks, HOWO dump trucks, trailer truck, truck parts, agricultural machinery, Construction machinery and parts,HOWO concrete mixer trucks, special trucks and so on.we can supply trucks for our clients with good quality and competitive price, because we get directly support from the CNHTC factory.

新重汽 37

Main products

1. Dump Truck / Tipper Truck

2. Hohan tractor Truck/ prime mover truck

3. Truck with crane / Truck mounted crane

4. Oil Tank Truck / Fuel Tanker Truck

5. Water truck / Water Tank Truck / Water Sprinkler Truck

6. Concrete Mixer Truck

7. Van truck / Insulated truck/ Refrigeration truck

8. Fecal suction truck / Sewage suction truck

9. Cement Powder Tank truck/ Bulk cement trailer

10. High-altitude operation truck

11. Semi Trailer ( flat bed trailer / skeleton trailer / dump trailer / side wall trailer / low bed trailer / container trailer, etc. )

新重汽 38新重汽 39
