You are here: Home » Products » Truck » Bus » DD6109C01-COACH (Diesel) BUS

DD6109C01-COACH (Diesel) BUS

DD6109C01-COACH (Diesel) BUS

EngineYC6L260-42,191KW/2200rpm,260hp

Gearbox:6DS100T Shanchi

Axle:Front axle 5.5T SG;Drive axle11T SG

Tire:wheel rim 8.25X22.5,11R22.5

Numbers of seats43+1

With A/C 26000 KCal

Availability:
Quantity:
  • DD6109C01

  • Huanghai

Product Description

新重汽 32


Our company has been engaged in the export business of automobiles and accessories, and all employees have rich experience in automobile production and export.



The main business scope includes the production, sales and service of automobiles and accessories. The main models include vans, buses, bus chassis,,SUV, and EV (electric vehicles); and spear parts of YUTONG,KINGLONG, HIGER, ZHONGTONG and other brand buses.



Our company can also supply SKD and CKD parts to the market to save import tariffs. Professional and diligent sales team and technical service team always serve customers.

客车 1-1

DD6109C01-COACH (Diesel) SPECIFICATION

Vehicle Parameters

Overall length(mm)

10600

Overall width(mm)

2550

Overall height(mm)

3540

Gross weight (kg)

15600

Curb weight (kg)

11300

Door Steps

2

Numbers of seats

43+1

Seats layout

2+2

Passenger capacity (persons)

44

Vehicle Performance

Maximum speed(km/h)

100

wheel base (mm)

4300

wheel track (mm)

2070/1860

Front/rear overhang (mm)

2340/3200

Approach /departure angle°

8/8

Engine

Engine model

YC6L260-42

Emmision

Euro 4

Fuel

Diesel

Fuel tank capacity(L)

320L

Chassis

Drive axle

11T SG

Front axle

5.5T SG

Gearbox

6DS100T  Shanchi

Tire

11R22.5

wheel rim

8.25X22.5

Steering system

Locally made in China

Braking system

Front disc & rear drum

Suspension

Air suspension

Drier

Locally made in China

ABS

Locally made in China

Retarder

Locally made in China

Main bodywork facilities

Body frame

Semi-monocoque body structure

Passenger door(front)

Single outward swing door in front and middle  (aluminium alloy)

Front windshield window

Double curved laminated glass

Rear  windshield window

Tempered glass

Driver window

Built-in sliding window

Side window

Built-in sliding window

Front sunshade curtain

Manual

Driver seat

SJ-JZP-3A

Other seats

LY-PBT-01,nonadjustable

Floor

Wooden +wearing-resistant floor

Instrument panel

Softened

Painting

Domestic color painting

Interior mirror

Rectangular type with large view

Rearview mirror

Manual electric defrosting

Heating

No heating, with defroster

Ventilation

Safety skylight 2 units (plastic)

Electrical service facilities

Lamp

Roof lamps, 3units

A/C

26000 KCal

Battery

6-QA-165(2 units)

Wiper

Horizontal wipers

Driving recorder

Equipped

Safety facilities

Temperature alarm

Compartment temperature alarm

Fire extinguisher

4 Kg(2 units)

Emergency hammer

4 units with alarming function

Driver safety belt

Equipped

Packing

Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.

The manufacturer reserves the right of technical alteration /change for better improvement without prior notice

客车 2

Exceptional Quality Secures Driving Enjoyment

Safe, energy-saving and environmental design philosophy and proven workmanship bring exceptional and steady quality, which can fully meet with customers' diverse demands, naely passenger transportation, tourism and group activity; the ergonomic design makes the driver happy and worry free;



Intensive Caring, More Comfort

Beside the soft tone, the interior style is concise and generous; the onboard audio-visual system enriches the journey; the passenger door is equipped with LED lamp so that passengers may safely get on/off the vehicle at night; space between seats is maximized so that passengers can be fully extended.



Calm Driving, Mobility Enjoyment

More spacious driver zone can provide a comfortable maneuverability environment; the foot pedal specially intended for the driver can effectively alleviate tiredness during long-haul driving; the dashboard is integrated with more advanced factors, and steady structure of the complete vehicle makes the driver calmly cope with changeable road conditions.

客车 1-2

客车 1-3
