Tyre Wheel Mobile Jaw Crusher Plant
Appication Industry：Construction works
Type:Mobile Combination
Motor type:AC motor
Capacity(tph):85-850
Production:Mobile Cone Crusher
Raw Material:Pebble,limestone,granite,Basalt
| Quantity: | |
|---|---|
YG1149E750
XCMG
SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.
We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.
Tyre Wheel Mobile Jaw Crusher Plant | |||||
Model | YG938E69 | YG1149E750 | YG1349C760 | YG1349C912 | |
Transportation Length(mm) | 12600 | 13500 | 14500 | 15200 | |
Transportation Width(mm) | 2600 | 2700 | 2800 | 2900 | |
Transportation Height(mm) | 3870 | 4200 | 4450 | 4500 | |
Maximum Length(mm) | 12500 | 14000 | 16100 | 14700 | |
Maximum Width(mm) | 4100 | 4500 | 5100 | 5100 | |
Maximum Height(mm) | 4100 | 4900 | 5000 | 5300 | |
Weight(t) | 39 | 57 | 55 | 65 | |
Tire Configuration | Dual-axial | Dual-axial | Dual-axial | Dual-axial | |
Jaw Crusher | PE600*900 | PE750*1060 | JC760 | PE900*1200 | |
Maximum Feeding Size(mm) | 500 | 550 | 660 | 800 | |
Discharge Opening Size(mm) | 50-150 | 75-175 | 100-200 | 125-225 | |
Capacity(t/h) | 85-275 | 110-350 | 215-510 | 280-650 | |
Vibrating Feeder Model | ZSW380×95 | ZSW420×110 | ZSW490×130 | ZSW490×130 | |
Main Belt Conveyor | B800×8.5M | B1000×9.5M | B1000×11M | B1200×11M | |
Side-opening Belt conveyor(Optional) | B500×3M | B650×3.5M | B650×4M | B650×4M | |
Genset(Optional) (kw) | 200 | 250 | 270 | 400 | |
Iron Separator (Optional) | RCYD(C)-8 | RCYD(C)-10 | RCYD(C)-10 | RCYD(C)-12 | |
Packing | Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity. | ||||
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice | |||||
Product Introduction
The Mobile Jaw Crusher Plant is a new type rock crushing device developed by our company, which greatly expands the filed of rough crushing operation. Its design philosophy is to stand on the customer's side and to provide an important solution to the obstacles that eliminate broken ground and environment to customers' crushing operations. Really provide customers with efficient and low-cost project operation hardware facilities.
Feeding Opening: 400-1200mm
Capacity: 15-385 tph
Applications: mining industrial, coal mines, garbage and construction waste, earth and stone works, urban infrastructure, roads or construction sites.
Applicable materials: river pebble, rock (limestone, granite, basalt, diabase, andesite, etc.), ore tailings
Main Features of Mobile Crushing Plant
1) Optimized design of ship form frame structure, low vehicle chassis, compact and reasonable structure, modular assembly structure, small turning radius and convenient transportation.
2) Folding type feeding bin, hydraulic support guard board, easy and reliable operation.
3) Control cabinet equips with advanced words touch control screen, PLC control system, ensuring fuctions of starting, process adjustment, misoperation tip & protection, electric control operation, fault and safety warning.
4) Feeder can presort fine materials ; Automatic design of stock bin door, which can control direction of material dividing.
5) The angle of conveyor is adjustable. Conveyor can be turned and folded, which extends operation conditions and realize easy transportation.
6) The equipment adopts stream-line structure, compact and reasonable mechanics optimization structure.
7) Hydraulic rise and fall, easy and flexiable operation.
8)According to customers' requirements, we can produce any combinated and non-standard mobile crushing plant.
General configuration of equipments are as follows:
1.Vibrating feeder+jaw crusher+impact crusher+belt conveyor+circular vibrating screen.
2.Vibrating feeder+jaw crusher+cone crusher+belt conveyor+circular vibrating screen.
3.Vibrating feeder+jaw crusher+impact crusher+VSI sand making machine+belt conveyor+circular vibrating screen.
Structure
The parts of mobile jaw crusher plant includes: frame, jaw crusher, feeder, vibrating screen, belt conveyor, motor and control box.
Working Principle
Materials are transported to the jaw crusher through the feeder, after the primary crushing of jaw crusher, using the circular vibrating screen to realize recycling crushing. The finished materials are transported out by the belt conveyor to be crushed continuously. Mobile jaw crusher plant can remove circular vibrating screen according to the actual production needs to realize the primary crushing directly. It has the advantage of simple and flexible operation.
Usage Scope
1. It is widely used in mine, quarrying, rubbish, the recycling of construction waste, earth and stone works, urban infrastructure, road, building site and so on.
2. Handle topsoil and other various materials; separate viscidity coagulation aggregate; the screening after crushing.
3. Manufactured sand for river gravel, hillstone (limestone, granite, basalt, diabase, andesite, etc., ore tailings, aggregate chips and so on.
