Rectangular DOT Plateau Tractor Truck

SINOTRUK HOWO 6X4 Tractor Truck

Model: ZZ4257S3241W

Cab:HW76,with one sleep,with A/C

Engine:WD615.47.; 371hp; Euro II,with silicone oil fan,180Ah battery,intake pipe heater.

Transmission: HW19710,10 forward and 2 reverse.

Steering: ZF8118Left hand driving

Axles: Front:9000kg &  Rear: 2*16000kg

Tire: 12.00R20 radial tyre, with 1 Spare tire.

Fifth:90#(3.5 inch)

Oil Tank:400L

with metal pipeline.

Availability:
Quantity:
  • ZZ4257S3241W

  • SINOTRUK HOWO

Product Description

新重汽 32

1. Tractor trucks with the engine  are all equipped with heating and air conditioning which are electrically operated and automatically control temperature. This is the configuration for high-end sedan.

2. The sleeper of our product is designed according to the body shape of European and American people. The width reaches 600mm. The aluminum alloy frame has light weight and good rigidity. A wire mesh structure is internally installed. Compared with other products in the domestic market, our product can more effectively relieve fatigue.

新重汽 36

SINOTRUK HOWO 6x4 TRACTOR TRUCK SPECIFICATIONS

Truck Model

ZZ4257S3241W(Left Hand Drive )

Truck Brand

SINOTRUK-HOWO

Dimension (LxWxH) (unloaded)mm

6900×2550×3250

Approaching angle/ Departure angel (°)

16/70

Overhang (front/rear) (mm)

1500/700

Min Turning Radius(m)

9m

Wheel base (mm)

3200

Max. Driving speed (km/h)

102

Front axle loading capacity (kg)

9000

Rear axle loading capacity(kg)

2*16000

Curb weight (kg)

9180

Gross vehicle weight

25000

Cab Model

SINOTRUK HW76 Lengthen cab,single bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner

Engine Model

Model

WD615.47(EURO II),371hp,6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection

Rated Power(kw/rpm)

273/2200

Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80℃ opening begin, silicone oil fan,180Ah battery,intake pipe heater.

Clutch

SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance

Transmission

Model

SINOTRUK HW19710 transmission ,10 forward and 2 reverse.

Brake system



Service brake

Dual circuit compressed air brake

Parking Brake

(emergency brake)

Spring energy, compressed

Auxiliary brake

Engine exhaust brake,EVB,with metal pipeline.

Steering system

Model

ZF8118 Steering Gear Box ,hydraulic steering with power assistance.

(Left hand driving)

Front axle

SINOTRUK VGD95 9500kg Front Axle,new 9.5-ton front axles of equipped with drum brakes.

Rear axle

SINOTRUK MCP16ZG 2*16000 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:4.42;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.

Wheels &Tire

Rims:8.5-20 10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire.

Electrical system

Electrics Operating voltage

24V,negative grounded

Starter

24V,7.5 Kw

Alternator

3-phase,28V,1500 W

Batteries

2x12 V,180 Ah

horn,headlamps,fog lights,brake lights,indicators and reverse light

Oil Tank

Square type-400L fuel tank

Fifth

90#(3.5 inch)

Packing

Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.

The manufacturer reserves the right of technical alteration /change for better improvement without prior notice

We are the agency for SINOTRUK wholesale truck series, we can supply HOWO tractor trucks, HOWO dump trucks, trailer truck, truck parts, agricultural machinery, agricultural machinery parts,HOWO concrete mixer trucks, special trucks and so on.we can supply trucks for our clients with good quality and competitive price, because we get directly support from the CNHTC factory.

新重汽 37

Main products

1. Dump Truck / Tipper Truck

2. Hohan tractor Truck/ prime mover truck

3. Truck with crane / Truck mounted crane

4. Oil Tank Truck / Fuel Tanker Truck

5. Water truck / Water Tank Truck / Water Sprinkler Truck

6. Concrete Mixer Truck

7. Van truck / Insulated truck/ Refrigeration truck

8. Fecal suction truck / Sewage suction truck

9. Cement Powder Tank truck/ Bulk cement trailer

10. High-altitude operation truck

11.Semi Trailer ( flat bed trailer / skeleton trailer / dump trailer / side wall trailer / low bed trailer / container trailer, etc. )

新重汽 35
