Vertical Shaft Impact Crusher (VSI Crusher)
Max. Feed Size: 30-60 mm
Processing Capacity: 16-715 TPH
Output Size: 0-5 mm
Application Fields: water conservancy, refractory material, construction, highway, railway, etc.
Applied Materials: granite, basalt, greenstone, sandstone.
Customized Service: Small, medium and large models can be customized to meet your needs.
Availability: | |
---|---|
Quantity: | |
Vertical Shaft Impact Crusher
SINOCTM
SINOCTM is located in Ji′Nan city, Shandong province, SINOCTM aims to provide the project solutions with best cost performance to customers from China and abroad. Our main business are construction solutions consultancy, equipments supply, technical instruction, parts supply, service & training, logistic support and etc, providing the steward type service.
We cooperate with SINOTRUK, FOTON, SDLG, XCMG, Liugong, Shantui, Sany, Zoomlion, Hongda and other premium brands to provide tailored project solutions to your specific needs. We can help you to avoid long-time communication with different suppliers, which will save you time and cost. As to after market, with many years′ experience in the industry and long-term partnership with the suppliers, we do provide timely after market with lower cost and higher availability.
Model | Max. Feed Size(mm) | Impeller Speed(r/min) | Power(kw) | Capacity(t/h) | Weight(kg) |
PLS-550 | 30 | 2258-2600 | 30-45 | 24-60 | 4780 |
PLS-700 | 35 | 1775-1965 | 55-110 | 55-120 | 7500 |
PLS-850 | 50 | 1320-1720 | 150-320 | 75-345 | 11500 |
PLS-1000 | 60 | 1240-1460 | 320-500 | 200-585 | 17000 |
PLS-1200 | 60 | 1040-1300 | 500-630 | 300-715 |
Description
Beyond the traditional crushing theory, PLS Vertical Shaft Impact Crusher (VSI Crusher / Sand Making Machine)has the features of low cost, good adaptability and throughout, wide application etc. Until now the company sold thousands of the machines in China as well as overseas in many industries with good reputation.
VSI Sand Crusher is widely used in many industries, especially for artificial sand making, quartz sand making, and silica sand making, with high quality and even-shaped finished product usually no more than 5mm.
Features
1. The design of deep cavity makes more space for the impeller which can improve the efficiency.
2. Reasonable inner structure makes the material protect itself, which makes the life of the impeller longer. And the cost will be lower.
3. There are different speeds (high, medium, low) to choose which can fully show the efficiency of the machine. It has the function of crushing, sand making and shape making.
4. The wear plate and hardfacing protect the impeller and make it safe and life long.
5. Higher accuracy of manufacture makes the anti-unbalanced ability of the impeller better.
6. The wear parts are standard modularity. It is convenient for maintenance.
Working Principle
Stone Beat Stone: The materials fall vertically and uniformly from the top of the machine. One part of them enter into the revolving impeller at high speed through the distributor and feed pipe, and are shoot out from the discharge outlet of impeller by the action of the high-speed centrifugal force. Then at high speed they are smashed with another part of the materials that have been distributed around impeller through the distributor. After smashing each other the materials shall form whirlpool and impact many times caused by striking and attrition in the impeller and crushing chamber.
Stone Beat Iron: The materials fall vertically and uniformly from the top of the machine, and enter into the revolving impeller at high speed through the feed pipe. Then they are shot out from the discharge outlets of impeller by the action of the high-speed centrifugal force, and at high speed strike and crush with impact plate around the impeller.
